Light Source:
Main Light: 5*120W，RGBL 4-in-1 LED
Outer Circle: 120*0.5 W，RGB 3-in-1 LED
Beam angle: 3°-30 °
Field Angle: 4°-35°
Control:
4 button Touch control panel
Display: LCD display
Control protocol: DMX512, RDM
DMX channel modes: 6
Control Channels:21/41/71/75/85/170 CH
Software upgrade: Upgrade via DMX link
Pan/ Tilt:
Pan Movement: 59°
Tilt Movement:221°
Electrical and Connectors
Input Voltage Range: 180-240V~50 / 60Hz
Power Consumption: 800 W
Power socket: Power connector in / out
Signal in/ out: 3-pin or 5-pin XLR, RJ45 connector
Other effects:
Multiple speed strobe effects
Variable light adjustment from 0-100% dimming
Extraordinary color-mixing function
Special color macro effect
Agile fast linear focus
Fixture Dimensions:
Dimensions: 1000 * 190 * 355mm
Weight: 27kg
Packaging Information
Carton Dimensions:1090*445*325mm
Gross weight : 31kg
Protection Rating:
IP20
