ATD Lighting
| Availability: | |
|---|---|
Electrical & Interface
Input Voltage: AC 100–240V, 50/60Hz
Power: 350W
Preset Shape effects stored in channels
Supports 3-pin/5-pin DMX51
Light Source
LEDs: 19 × 15W OSRAM Ostar RGBW 4-in-1 LED chips
LED Lifespan: ≥50,000 hours
Color Temperature: 2,500–8,000K, linearly adjustable
Optical System
Motorized Zoom Range: 4°–60°
Features: Individual LED pixel control (for beam, wash, graphic, and effects)
Effects Modes: Vortex, Kaleidoscope, Prism
Front Lens Rotation: Bidirectional continuous rotation
Control
Control Protocol: 3-pin DMX512 (standard)
Channel Modes: 23/35/78/92/96 channels
Finish: Black with LCD display
Effects
Dimming: 0–100% linear electronic dimming
Strobe: Adjustable speed (1–25Hz) with instant blackout
Pan/Tilt
Pan Movement: 540°
Tilt Movement: 270°
with electronic error correction
Fixture specifications
Housing Material: Die-cast aluminum
Dimensions (W×H×D): 420 × 260 × 470mm
Weight: 15.5kg
Packaging Information
Carton Dimensions:490*355*465mm
Gross weight : 18.5kg
